模具誤送檢知 SD-101 / 通過檢知 SD-201

Stamping Die Error- Carrying Device SD-101/ Passing Through
Inspection Devices SD-201


同期訊號和角度圖

The chart of symchronization signal and angle

無接點式 : 近接開關作排料和同期檢出, 基準輸入時間和角度關系圖

NON-CONTACT CHECKING METHOD:
Limit Switch used to do discharge
and synchronization check.
The chart shows the relation
between the input signal
tine and the angle.
